It works great, but expanding the storage with a MicroSD was essential.
Blacksmith3d 6 tablet setup for navigation pro#
It came with Google maps, but I've added Back Country Navigator Pro (rad!) and Torque Pro (also rad!), plus a handful of miscellaneous stuff. I originally bought it for taking notes in college a few years back, which it was great for, but recently I've using it for navigation and social media while on the road. I have an older Galaxy Note 8.0 (with S-Pen). If the correct selection has been made, you should see the GPS status icon change from red to green.As long as your tablet has a decent internal GPS and sufficient storage, I don't think the specific model really matters all that much. Set the “Baud Rate” to 4800 and click “OK”. Some manufacturers make it obvious, like ”/dev/cu.MiniPlex-99000125“, but others may be more generic, like: ”/dev/cu.usbserial“.
It is not always obvious which is the correct one, but in general the device will have a name starting: ”/dev/cu.“ or ”/dev/tty.“.
Open the “Dataport” menu & select the device from the list.
Blacksmith3d 6 tablet setup for navigation driver#
When the driver is installed and the device connected, start OpenCPN, select the Options icon and click the Connections tab.
Blacksmith3d 6 tablet setup for navigation drivers#
Both those companies make OS X drivers available on their web sites, but manufacturers of GPS devices usually package the driver with device. Nearly all hardware uses one of just two chip makes: those from FTDI or Prolific. Whether using a device with its own USB lead or via a serial-USB adapter lead or an NMEA multiplexer with USB port, the appropriate OS X driver needs to be installed. if this is the case, use the following fix:Īttaching a GPS device to a Mac is done via one of the USB ports. If it works, try running opencpn without sudo, chances are that you cannot see the gps. To check that it works (/dev/rfcomm0 under GPS NMEA data source).
Your bluetooth GPS should now be working in open CPN. In a separate terminal, you can test the connection with You only need to to this once, not required if you reboot at this point). Sudo rfcomm release 0 (not strictly neccesary) # Automatically bind the device at startupĬhannel 1 #use channel number as provided by sdptool records XX:XX:XX:XX:XX:XX Pair GPS with bluetooth icon -break connection with bluetooth icon -get device id: sudo hcitool scan -get channel for gps: sdptool records 00:02:78:0A:4E:E9 (put your actual number here) -sudo gedit /etc/bluetooth/nf #edit rfcomm input file. That's it - you should now have a Bluetooth GPS Connected. Now in the NMEA Data Source options select from the pulldown menu: “ /dev/rfcomm0”, or write it in the box, if not present as an alternative. Now all you need to do is go into OpenCPN Toolbox and select GPS. Note put your GPS address in this line You should not have to run these commands each time your linux is restarted as it will remember your GPS address. Next we have to bind the GPS address to a “virtual” device OpenCPN understands in this case rfcomm0. In this case I have a IBT-GPS at address 00:1C:88:10:D3:4D (Your GPS address will be different) It will then start looking for the Bluetooth GPS and hopefully find your GPS. Once you have done that you will need to find what the address of the GPS is. If you have a bluetooth GPS you will need to first configure it through the standard Ubuntu Bluetooth “set up new device ” proceedure.
